Ikan Tally Router for Roland Switchers up to 4 Cameras

$339.99

Model: TI-OC-ROL-15-4

Four output ports to connect to Ikan monitor tally system
Compatible with standard ethernet cables
Direct connection to Roland Switcher’s Tally port
Includes power adapter and Roland switcher connection cable
Plug-and-play setup

Switcher Compatibility

V-40HD
V-440HD
V-800HD
V-800HD MKII
V-1600HD

In stock

Downloads

Manual: Tally Router for Roland - User Manual

SKU: TI-OC-ROL-15-4 Categories: Tally Solutions, Teleprompters

Tally Router Finder

Quickly find the right tally router for your switcher

Roland Switcher Tally Router for Ikan Tally Lights

Integrate your Roland switcher’s tally system with Ikan’s tally lights using this dedicated tally router . The solution creates direct, real-time communication between your Roland switcher and Ikan tally lights, so that whenever you change camera sources, the matching tally light instantly lights up. Talent and crew receive clear, immediate visual cues about which camera is currently on air.

Quad RJ45 Output System

Equipped with four RJ45 output ports, the router lets you connect multiple Ikan tally lights using ordinary Ethernet cables. This simple, standardized approach removes the hassle of custom wiring while delivering rock-solid tally signal distribution across your entire studio.

Direct Roland Integration

Plug straight into your Roland Video Switcher with the included cable and get instant tally functionality. The direct connection guarantees reliable signal transmission and eliminates any need for homemade cables or adapters.

Simple Installation

Everything is truly plug-and-play. Just connect power, attach the cable to your Roland switcher, and run standard Ethernet cables to your Ikan tally lights. No extra software, no drivers, no complicated configuration.

F.A.Q.

Setup Note for Roland V-440HD

If you’re using the Roland V-440HD, here are two quick things to know that will get you up and running in seconds:

1. Connect to the TALLY HD port. The V-440HD has two tally connectors — TALLY HD and TALLY SD — because it’s a multi-format switcher. Plug the included cable into TALLY HD for HD/RGB sources (the common setup). Use TALLY SD only if you’re switching standard-definition video.

2. Enable bi-color tally in the V-440HD menu. By default, the V-440HD may be set to program-only tally. To unlock both program (red) and preview (green) tally signals, navigate to System > 12. Tally Signal in the V-440HD menu and select Type 4, Type 5, or Type 6. Any of these three options will send full bi-color tally to your ikan tally lights.

Once those two things are set, the V-440HD behaves the same as every other Roland switcher in the compatibility list — change cameras on the switcher and the matching tally light lights up instantly.

Shipping Weight (lbs): 2
Shipping Dimensions (in): 7 x 7 x 7

What's Included:
1x Tally Router
1x Switcher Connection Cable

Tally Interface

Input Connector	DB9
Output Connectors	4x RJ45
Product Weight	1 lbs.
Length of Cable (end to end)	41"
Product Dimensions	3.25" x 4" x 1.33"
Build Material	Aluminum
